Touchscreen Toolkit for LabVIEW

Purchase $399

Free Trial

Have a Priority Code?

  • Increase Sales – Richer user experience for your applications
  • Reduce UI Clutter – Within interactive applications, buttons can be replaced by gestures
  • Reduce Footprint – Eliminate the need for a keyboard or mouse by using gestures and touch
  • Tablet Integration – Directly acquire data from on-board sensors such as accelerometers, gyroscopes, inclinometers, and light sensors


The Touchscreen Toolkit enables developers to create a richer user experience for their applications by providing a LabVIEW interface with both the Windows Touch API and Touch-Base Ltd’s Universal Pointer Driver Device (UPDD). Compatible with Windows 7/8/10, the Toolkit delivers the unique ability to zoom and pan within a LabVIEW graph’s x and y axis plus cursor control during data analysis – all via touch. With multi-touch capable touchscreens, this is the only way to enable gesture recognition in LabVIEW. A new feature now includes an interface to built-in sensors on Windows tablets including accelerometers, gyroscopes, inclinometers, orientation and light sensors.

The Touchscreen Toolkit includes a single seat development license and one deployment license good on the same machine the toolkit is activated on. Additional deployment licenses are available for $99 each. Contact Aledyne for unlimited deployment licensing options.

Supported Hardware

Tablets:Windows8 Tablet

Windows 8/10 touch tablets with on-board sensors are supported.  Multi-touch and gesture recognition can be utilized using the Touchscreen Toolkit for LabVIEW.  Directly acquire data from built-in sensors including accelerometers, gyroscopes, inclinometers, orientation and light sensors for a fully featured user experience.



Windows 7/8: Any Windows Touch Plug-And-Play touchscreen monitor is compatible with the Touchscreen Toolkit for LabVIEW.

Windows XP and WES7: Please refer to Touch-Base for a list of supported devices via the UPDD driver. A separate device driver is required for an additional fee of $171.


The MIMO Magic Touch 10.1” Monitor has been tested for compatibility with the Windows Touch API and the UPDD driver in the above Operating systems and can be purchased as a bundled option here.  This monitor has a single USB interface for video, touch, and power making it ideal for standalone LabVIEW applications running on single board computers.

National Instruments Standalone Hardware:

cDAQ-9138 and cDAQ-9139 CompactDAQ Stand-Alone chassis through the UPDD driver (sold separately).



  • Multiple monitor and multi-touch support for a wide variety of touch monitors
  • LabVIEW User event registration and triggering when touch occurs on any configured touchscreen
  • Disable mouse pointer so touches do not control mouse movement
  • Gesture recognition engine to enable LabVIEW applications for swipe/zoom/pan/rotate
  • Create front panel buttons with switch until released/switch when pressed touch properties
  • Simultaneously control one or more buttons and sliders with multitouch
  • Directly acquire data from on-board sensors such as accelerometers, gyroscopes, inclinometers, and light sensors
  • Directly integrates with the Windows 7/8/10
  • Integration with Windows XP and National instruments Standalone Hardware with the UPDD driver from Touch-Base (sold separately)

System Requirements

  • LabVIEW 2012 or higher
  • Multi-touch capable monitor for gesture recognition
  • UPDD driver or Windows 7, Windows 8, or Windows 10
